SEPARADOR 15dB (30:1) Tap 350-5930MHz 500W -161dBc 4.3-10 IP67 .

$ 4,125.34
Hacer una pregunta
Pago Seguro
trusted_page

Descripción

Descripción

Microlab DN-x4FE series of Tappers unevenly split high power cellular signals in fixed ratios from 1000:1 to 2:1 with minimal reflections or loss over the key wireless bands in the range 350 – 5,930 MHz, (there is no coupling 1550 to 1650 MHz). The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands, even down to a 2:1 split.

The lightweight design allows easy attachment to a wall using the supplied bracket. Designed with only a few solder joints and an air dielectric, loss is minimized and reliability enhanced. See DN-x4FN, and DN-x4FD series for similar Tappers with N, and 7/16 connectors.

Características
  • Split ratios from 1000:1 to 2:1
  • Tetra, PMR, Cellular, UMTS, WiFi to 5,930
  • Low Specified PIM
  • 500 W Avg Power Rating
  • Minimal RF Insertion Loss
  • RoHS compliant
  • High Reliability, IP67
Especificaciones
  • Frequency: 350 – 5,930 MHz
  • Ratio: 30:1/15dB
  • Main/Branch Split: -0.1/-15.3
  • Power: 500W avg., 3 kW peak
  • VSWR: 1.2:1 for 700-2500 MHz
  • 1.3:1 for 350-5930 MHz
  • PIM: -161 dBc (2 tones at +43dBm)
  • Connectors: 4.3-10 (f) trimetal
  • Ingress Protection: IP67
  • Weight: 0.875 lb (380 g)
Características Clave
  • Divisor de potencia 15dB (30:1) con alta precisión
  • Rango de frecuencia 350-5930MHz para múltiples aplicaciones
  • Potencia promedio 500W y pico 3kW resistente
  • PIM extremadamente bajo de -161dBc
  • Conectores 4.3-10 IP67 para uso profesional
  • Diseño compacto y liviano (380g) con soporte
